Thinking about adding some extra height to your Chevy truck? Learning how to lift a truck yourself is a rewarding project, but it requires careful planning, the right parts, and a solid understanding of what’s involved. Whether you’re driving a Silverado 1500 or a Colorado around Garland, Texas, this guide walks you through the key steps and components before you pick up a wrench.
What Type of Lift Is Right for Your Chevy Truck?
The first decision in how to lift a truck yourself is choosing the type of lift. The two most common options are a body lift and a suspension lift. A body lift raises the truck’s body itself off the frame using spacer blocks, which is a more straightforward and budget-friendly approach. A suspension lift modifies or replaces the entire suspension system, providing more ground clearance and better off-road performance.
For most DIYers, a body lift in the 2 to 3” range is a manageable starting point. A suspension lift delivers more dramatic results but comes with greater complexity and cost.
Understanding the Key Truck Parts Involved
Before diving in, it helps to know which components you’ll be working with. Here’s a breakdown of the main parts involved in a typical lift installation.
For a body lift, you’ll be working with body mount spacers, new longer body mount bolts, and sometimes extended bump stops. You may also need to adjust the steering shaft and relocate certain components like the radiator overflow tank or transmission shifter linkage depending on how high you’re going.
For a suspension lift, the parts list expands considerably. You’ll typically be replacing or modifying control arms, coil springs or coil spacers, shock absorbers, and brake line brackets. On 4WD Chevy trucks, the CV axles and differential drop brackets may also need attention to maintain proper driveline angles.
The Step-by-Step Lift Installation Process
Once you’ve selected your lift kit and gathered your parts, the installation process follows a logical sequence. Start by safely raising the vehicle on a quality floor jack and supporting it with jack stands—never rely on a jack alone. Remove the wheels to gain better access to suspension components.
For a body lift, loosen and remove the existing body mount bolts, insert the spacers, and reinstall with the longer bolts. Work from the front of the truck toward the rear to keep the body aligned as you go.
For a suspension lift, begin at the front by compressing and removing the coil springs using a proper spring compressor tool. Replace the springs or install spacers, then swap in the new shocks. Move to the rear and repeat the process. Reconnect all brake lines, check CV axle angles, and torque all fasteners to the manufacturer’s specifications.
After installation, a professional alignment is strongly recommended—this is not a step to skip.
How Much Does a Truck Lift Cost?
If you’re wondering how much a truck lift costs when doing it yourself, the savings can be significant. A basic body lift kit for a Chevy truck typically runs between $100 and $300. A quality suspension lift kit can range from $400 to over $1,500 depending on the brand and lift height.
DIY installation saves on labor, but keep in mind you’ll also need to factor in a post-install alignment, which generally costs $80 to $150. Understanding how much a truck lift costs upfront helps you budget accurately and avoid surprises midway through the project.
Stop By Garland, TX and Explore Our Lifted Chevy Truck Lineup
Knowing how to lift a truck yourself starts with having a great truck as the foundation. Chevy’s current truck lineup, including the Silverado, Silverado HD, and Colorado, offers a strong platform for customization. If you’re ready to find your next build, check out our selection of lifted Chevy trucks at Jupiter Chevrolet. Explore available inventory and get help finding the right Chevy truck for your next project.
